Jackie jacket
Jackie is a semi-fitted, fully lined jacket with a straight silhouette. The bust darts on the front are transferred to the side seams. The front features topstitched decorative flaps held in place with the sewn-on buttons. The long, set-in, two-piece sleeves have faux button vents in the elbow seams. The jacket features a stand collar and fastens with buttons and buttonholes at the center front. Jackie is above-the-hip length.
Approximate sewing time – 3 days (24 hours).
Model Vlada: Height 172 cm (5’8”), Bust 83 cm (32 5/8”), Waist 60 cm (23 5/8”), Hips 88 cm (34 5/8”). Vlada is wearing size 36 in height 3.
Model Ulyana: Height 176 cm (5’9”), Bust 83 cm (32 5/8”), Waist 62 cm (24 3/8”), Hips 90 cm (35 3/8”). Ulyana is wearing size 36 in height 3.
To sew this jacket, choose suiting fabrics with the following properties:
- medium weight, pliable, structured, non-stretch or low-stretch
- the fiber content can include natural fibers (wool), artificial fibers (viscose), blends (wool + silk, wool + polyester, etc.), and synthetics (polyester)
- the following fabrics are recommended: tweed, suiting, gabardine.
Attention! We do not recommend stretchy fabrics (knits), lightweight soft fabrics (dress-weight wool), or heavyweight wool fabrics.
For the lining, choose lining fabrics made of artificial fibers (viscose), blends (viscose + elastane, viscose + polyester), or synthetics (polyester, polyester + elastane).
The jacket in the photo is made of tweed. The fabric is medium weight, pliable, soft, structured and non-stretch. The fiber content is a blend of wool, polyester, and viscose. The fabric weight is 450 g/m2.
The lining is 100% viscose. The fabric weight is 50 g/m2.
1. Main fabric, 450 g/m2, 140 cm wide, with a directional print/nap, in meters:
Height, cm | Size | ||||||
34 | 36–38 | 40–42 | 44 | 46–48 | 50 | 52 | |
1 (154–160) | 1.2 | 1.25 | 1.3 | 1.3 | 1.35 | 1.4 | 1.6 |
2 (162–168) | 1.25 | 1.3 | 1.35 | 1.35 | 1.4 | 1.45 | 1.65 |
3 (170–176) | 1.3 | 1.35 | 1.4 | 1.45 | 1.45 | 1.5 | 1.75 |
4 (178–184) | 1.35 | 1.4 | 1.45 | 1.5 | 1.5 | 1.55 | 1.8 |
2. Main fabric, 450 g/m2, 150 cm wide, with a directional print/nap, in meters:
Height, cm | Size | ||||
34–38 | 40–44 | 46–48 | 50 | 52 | |
1 (154–160) | 1.2 | 1.25 | 1.3 | 1.35 | 1.4 |
2 (162–168) | 1.25 | 1.3 | 1.35 | 1.4 | 1.45 |
3 (170–176) | 1.3 | 1.35 | 1.4 | 1.45 | 1.5 |
4 (178–184) | 1.35 | 1.4 | 1.45 | 1.5 | 1.55 |
Main fabric, 450 g/m2, 55", with a directional print/nap, in yards:
Height, ft | Size | ||||||
34 | 36–38 | 40–42 | 44 | 46–48 | 50 | 52 | |
1 (5’1”–5’3”) | 1 1/4 | 1 3/8 | 1 3/8 | 1 3/8 | 1 1/2 | 1 1/2 | 1 3/4 |
2 (5’4”–5’6”) | 1 3/8 | 1 3/8 | 1 1/2 | 1 1/2 | 1 1/2 | 1 5/8 | 1 3/4 |
3 (5’7”–5’9”) | 1 3/8 | 1 1/2 | 1 1/2 | 1 5/8 | 1 5/8 | 1 5/8 | 1 7/8 |
4 (5’10”–6’1”) | 1 1/2 | 1 1/2 | 1 5/8 | 1 5/8 | 1 5/8 | 1 3/4 | 2 |
Main fabric, 450 g/m2, 59", with a directional print/nap, in yards:
Height, ft | Size | ||||
34–38 | 40–44 | 46–48 | 50 | 52 | |
1 (5’1”–5’3”) | 1 1/4 | 1 3/8 | 1 3/8 | 1 1/2 | 1 1/2 |
2 (5’4”–5’6”) | 1 3/8 | 1 3/8 | 1 1/2 | 1 1/2 | 1 5/8 |
3 (5’7”–5’9”) | 1 3/8 | 1 1/2 | 1 1/2 | 1 5/8 | 1 5/8 |
4 (5’10”–6’1”) | 1 1/2 | 1 1/2 | 1 5/8 | 1 5/8 | 1 3/4 |
Important! If you sew with chequered or striped fabric, add 2 pattern repeats to the fabric requirements when buying the fabric.
2. Lining fabric, 50 g/m2, 140 cm wide, with a directional print, in meters:
Height, cm | Size | ||||
34–38 | 40 | 42–46 | 48–50 | 52 | |
1 (154–160) | 1.05 | 1.1 | 1.1 | 1.15 | 1.25 |
2 (162–168) | 1.1 | 1.1 | 1.15 | 1.2 | 1.3 |
3 (170–176) | 1.15 | 1.15 | 1.2 | 1.25 | 1.35 |
4 (178–184) | 1.2 | 1.2 | 1.25 | 1.3 | 1.4 |
Lining fabric, 50 g/m2, 55" wide, with a directional print, in yards:
Height, ft | Size | ||||
34–38 | 40 | 42–46 | 48–50 | 52 | |
1 (5’1”–5’3”) | 1 1/8 | 1 1/4 | 1 1/4 | 1 1/4 | 1 3/8 |
2 (5’4”–5’6”) | 1 1/4 | 1 1/4 | 1 1/4 | 1 1/4 | 1 3/8 |
3 (5’7”–5’9”) | 1 1/4 | 1 1/4 | 1 1/4 | 1 3/8 | 1 1/2 |
4 (5’10”–6’1”) | 1 1/4 | 1 1/4 | 1 3/8 | 1 3/8 | 1 1/2 |
3. Interfacing, 70 g/m2, 140 cm wide, in meters:
Height, cm | Size | ||||||
34 | 36–38 | 40–42 | 44 | 46–48 | 50 | 52 | |
1 (154–160) | 1.3 (1.2; 0.1) | 1.35 (1.25; 0.1) | 1.4 (1.3; 0.1) | 1.4 (1.3; 0.1) | 1.45 (1.35; 0.1) | 1.5 (1.4; 0.1) | 1.7 (1.6; 0.1) |
2 (162–168) | 1.35 (1.25; 0.1) | 1.4 (1.3; 0.1) | 1.45 (1.35; 0.1) | 1.45 (1.35; 0.1) | 1.5 (1.4; 0.1) | 1.55 (1.45; 0.1) | 1.75 (1.65; 0.1) |
3 (170–176) | 1.4 (1.3; 0.1) | 1.45 (1.35; 0.1) | 1.5 (1.4; 0.1) | 1.55 (1.45; 0.1) | 1.55 (1.45; 0.1) | 1.6 (1.5; 0.1) | 1.85 (1.75; 0.1) |
4 (178–184) | 1.45 (1.35; 0.1) | 1.5 (1.4; 0.1) | 1.55 (1.45; 0.1) | 1.6 (1.5; 0.1) | 1.6 (1.5; 0.1) | 1.65 (1.55; 0.1) | 1.9 (1.8; 0.1) |
Interfacing, 70 g/m2, 55" wide, in yards:
Height, ft | Size | ||||||
34 | 36–38 | 40–42 | 44 | 46–48 | 50 | 52 | |
1 (5’1”–5’3”) | 1 3/8 (1 1/4; 1/8) | 1 1/2 (1 3/8; 1/8) | 1 1/2 (1 3/8; 1/8) | 1 1/2 (1 3/8; 1/8) | 1 5/8 (1 1/2; 1/8) | 1 5/8 (1 1/2; 1/8) | 1 7/8 (1 3/4; 1/8) |
2 (5’4”–5’6”) | 1 1/2 (1 3/8; 1/8) | 1 1/2 (1 3/8; 1/8) | 1 5/8 (1 1/2; 1/8) | 1 5/8 (1 1/2; 1/8) | 1 5/8 (1 1/2; 1/8) | 1 3/4 (1 5/8; 1/8) | 1 7/8 (1 3/4; 1/8) |
3 (5’7”–5’9”) | 1 1/2 (1 3/8; 1/8) | 1 5/8 (1 1/2; 1/8) | 1 5/8 (1 1/2; 1/8) | 1 3/4 (1 5/8; 1/8) | 1 3/4 (1 5/8; 1/8) | 1 3/4 (1 5/8; 1/8) | 2 (1 7/8; 1/8) |
4 (5’10”–6’1”) | 1 5/8 (1 1/2; 1/8) | 1 5/8 (1 1/2; 1/8) | 1 3/4 (1 5/8; 1/8) | 1 3/4 (1 5/8; 1/8) | 1 3/4 (1 5/8; 1/8) | 1 3/4 (1 5/8; 1/8) | 2 1/8 (2; 1/8) |
IMPORTANT! When purchasing fabric, please account for shrinkage and buy 5% more than required.
4. Stitched bias-cut fusible stay tape with stitch reinforcement, 1.5 cm (5/8") wide — 4 m (4 3/8 yd)
5. One pair of shoulder pads
6. One pair of sleeve heads
7. Nine buttons, 2.2 cm (7/8") in diameter
8. Eight buttons, 1.5 cm (5/8") in diameter
9. Matching thread — 1 spool.
- sewing machine for construction
- buttonhole foot for the sewing machine.
Ease type | Ease measurement, cm | Ease measurement, in |
Bust ease | 15.8–17.7 | 6 1/4–7 |
Waistline ease | 35.9 | 14 1/8 |
Upper arm ease | 5.4–6.4 | 2 1/8–2 1/2 |
Height, cm | Garment length, cm | Sleeve length, cm |
1 (154–160) | 49.4–52.2 | 61–62.5 |
2 (162–168) | 52.7–55 | 63–64.4 |
3 (170–176) | 55.4–59 | 65–66.3 |
4 (178–184) | 58.4–61.1 | 67–68.3 |
Height, ft | Garment length, in | Sleeve length, in |
1 (5’1”–5’3”) | 19 1/2–20 1/2 | 24–24 5/8 |
2 (5’4”–5’6”) | 20 3/4–21 5/8 | 24 3/4–25 3/8 |
3 (5’7”–5’9”) | 21 3/4–23 1/4 | 25 5/8–26 1/8 |
4 (5’10”–6’1”) | 23–24 | 26 3/8–26 7/8 |
Once the order is paid, within 1 minute you will receive an email with the details of the order and a link to your personal account, where the following will be available for download:
1. The pdf pattern in your chosen size, in the following formats: Letter, A4, A0 and plotter format. The size of the plotter format is indicated in the name of the document. You will need a plotter printer that can print at least 900mm width. Note that for height categories 3 and 4, the plotter pattern comes on 2 pages.
2. Detailed instructions which include cutting layouts, construction steps accompanied by photos, as well as instructions on how to work with Vikisews patterns (printing, taping, adjusting, sewing terminology).
If you have any questions, please let us know at info@vikisews.com
