Hayden coat
Hayden is a semi-fitted trapeze coat with raglan sleeves flared at the hem. The bust darts have been transferred into the centre front seams. The front features welt pockets with curved edges. Hayden has a turn-down collar with a separate collar stand. It is ankle length and fully lined. The coat fastens with snaps.
Model Sofia: Height 172 cm (5’8”), Bust 84 cm (33 1/8”), Waist 64 cm (25 1/4”), Hips 90 cm (35 3/8”). Sofia is wearing size 36 in height 3.
Approximate sewing time – 20 hours (2 days).
To sew this coat, choose suiting and coating fabrics with the following properties:
- medium weight, soft, non-stretch or with very little stretch
- the fiber content can include natural fibers (wool, cashmere), artificial fibers (viscose), blends (wool + cashmere, wool + polyester, etc.), and synthetics (polyester, polyester + elastane)
The following fabrics are recommended: coating-weight cashmere or wool, heavyweight tweed.
Attention! We do not recommend using lightweight raincoat fabrics.
For the lining, we recommend using artificial fibers (viscose), blends (viscose + elastane, viscose + polyester), and synthetics (polyester, polyester + elastane).
The coat in the photo is made of coating-weight cashmere. The fabric is medium weight, soft, malleable, non-stretch and has low pile. The fiber content is a blend of cashmere and wool.
The lining's fiber content is a blend of viscose and polyester.
1. Main fabric, 140 cm wide, with a directional print/nap, in meters:
Height, cm | Sizes | |||||||||
34 | 36 | 38 | 40 | 42 | 44 | 46 | 48 | 50 | 52 | |
3.05 | 3.05 | 3.1 | 3.1 | 3.15 | 3.25 | 3.4 | 3.4 | 3.45 | 3.55 | |
2 (162–168) | 3.15 | 3.2 | 3.2 | 3.25 | 3.3 | 3.4 | 3.55 | 3.55 | 3.55 | 3.65 |
3 (170–176) | 3.3 | 3.3 | 3.35 | 3.35 | 3.4 | 3.5 | 3.65 | 3.65 | 3.7 | 3.75 |
4 (178–184) | 3.4 | 3.45 | 3.45 | 3.5 | 3.55 | 3.65 | 3.75 | 3.75 | 3.8 | 3.85 |
Main fabric, 150 cm wide, with a directional print/nap, in meters:
Height, cm | Sizes | |||||||
34 | 36 | 38 | 40–44 | 46 | 48 | 50 | 52 | |
1 (154–160) | 2.55 | 2.6 | 2.7 | 2.85 | 2.85 | 2.9 | 2.95 | 3.05 |
2 (162–168) | 2.65 | 2.7 | 2.75 | 2.95 | 3 | 3 | 3.05 | 3.1 |
3 (170–176) | 2.75 | 2.8 | 2.85 | 3 | 3.1 | 3.1 | 3.15 | 3.25 |
4 (178–184) | 2.85 | 2.9 | 2.95 | 3.1 | 3.15 | 3.2 | 3.25 | 3.35 |
Main fabric, 55" wide, with a directional print/nap, in yards:
Height, ft | Sizes | |||||||||
34 | 36 | 38 | 40 | 42 | 44 | 46 | 48 | 50 | 52 | |
1 (5’1”–5’3”) | 3 3/8 | 3 3/8 | 3 3/8 | 3 3/8 | 3 1/2 | 3 1/2 | 3 3/4 | 3 3/4 | 3 3/4 | 3 7/8 |
2 (5’4”–5’6”) | 3 1/2 | 3 1/2 | 3 1/2 | 3 1/2 | 3 5/8 | 3 3/4 | 3 7/8 | 3 7/8 | 3 7/8 | 4 |
3 (5’7”–5’9”) | 3 5/8 | 3 5/8 | 3 5/8 | 3 5/8 | 3 3/4 | 3 7/8 | 4 | 4 | 4 | 4 1/8 |
4 (5’10”–6’1”) | 3 3/4 | 3 3/4 | 3 3/4 | 3 7/8 | 3 7/8 | 4 | 4 1/8 | 4 1/8 | 4 1/8 | 4 1/4 |
Main fabric, 59" wide, with a directional print/nap, in yards:
Height, ft | Sizes | |||||||
34 | 36 | 38 | 40–44 | 46 | 48 | 50 | 52 | |
1 (5’1”–5’3”) | 2 3/4 | 2 7/8 | 3 | 3 1/8 | 3 1/8 | 3 1/8 | 3 1/4 | 3 3/8 |
2 (5’4”–5’6”) | 2 7/8 | 3 | 3 | 3 1/4 | 3 1/4 | 3 1/4 | 3 3/8 | 3 3/8 |
3 (5’7”–5’9”) | 3 | 3 | 3 1/8 | 3 1/4 | 3 3/8 | 3 3/8 | 3 1/2 | 3 1/2 |
4 (5’10”–6’1”) | 3 1/8 | 3 1/8 | 3 1/4 | 3 3/8 | 3 1/2 | 3 1/2 | 3 1/2 | 3 5/8 |
2. Lining fabric, 140 cm wide, with a directional print/nap, in meters:
Height, cm | Sizes | ||||||
34–36 | 38–40 | 42 | 44–46 | 48 | 50 | 52 | |
1 (154–160) | 2.05 | 2.1 | 2.15 | 2.2 | 2.4 | 2.45 | 2.55 |
2 (162–168) | 2.15 | 2.2 | 2.25 | 2.3 | 2.45 | 2.5 | 2.6 |
3 (170–176) | 2.25 | 2.3 | 2.35 | 2.4 | 2.5 | 2.6 | 2.7 |
4 (178–184) | 2.35 | 2.4 | 2.45 | 2.5 | 2.6 | 2.7 | 2.8 |
Lining fabric, 55" wide, with a directional print/nap, in yards:
Height, ft | Sizes | ||||||
34–36 | 38–40 | 42 | 44–46 | 48 | 50 | 52 | |
1 (5’1”–5’3”) | 2 1/4 | 2 1/4 | 2 3/8 | 2 3/8 | 2 5/8 | 2 5/8 | 2 3/4 |
2 (5’4”–5’6”) | 2 3/8 | 2 3/8 | 2 1/2 | 2 1/2 | 2 5/8 | 2 3/4 | 2 7/8 |
3 (5’7”–5’9”) | 2 1/2 | 2 1/2 | 2 5/8 | 2 5/8 | 2 3/4 | 2 7/8 | 3 |
4 (5’10”–6’1”) | 2 5/8 | 2 5/8 | 2 5/8 | 2 3/4 | 2 7/8 | 3 | 3 |
IMPORTANT! When purchasing fabric, please account for shrinkage and buy 5% more than required.
3. Woven or knit interfacing, 140 cm wide, cut in any direction, in meters:
Height, cm | Sizes | ||||||
34–40 | 42 | 44 | 46 | 48 | 50 | 52 | |
1 (154–160) | 1.6 | 1.6 | 1.6 | 1.65 | 1.65 | 1.7 | 1.7 |
2 (162–168) | 1.6 | 1.6 | 1.7 | 1.7 | 1.75 | 1.75 | 1.8 |
3 (170–176) | 1.65 | 1.7 | 1.7 | 1.75 | 1.75 | 1.8 | 1.85 |
4 (178–184) | 1.7 | 1.75 | 1.75 | 1.8 | 1.8 | 1.9 | 1.9 |
Woven or knit interfacing, 55" wide, cut in any direction, in yards:
Height, ft | Sizes | ||||||
34–40 | 42 | 44 | 46 | 48 | 50 | 52 | |
1 (5’1”–5’3”) | 1 3/4 | 1 3/4 | 1 3/4 | 1 3/4 | 1 3/4 | 1 7/8 | 1 7/8 |
2 (5’4”–5’6”) | 1 3/4 | 1 3/4 | 1 7/8 | 1 7/8 | 1 7/8 | 1 7/8 | 2 |
3 (5’7”–5’9”) | 1 3/4 | 1 7/8 | 1 7/8 | 1 7/8 | 1 7/8 | 2 | 2 |
4 (5’10”–6’1”) | 1 7/8 | 1 7/8 | 1 7/8 | 2 | 2 | 2 1/8 | 2 1/8 |
4. Five snaps, 2.5–3 cm (1–1 1/8") in diameter
5. Matching thread — 1 spool for the sewing machine
- sewing machine for construction.
Ease type | Ease measurement, cm | Ease measurement, in |
Bust ease | 19.2–19.5 | 7 1/2–7 5/8 |
Waistline ease | 49.3–50 | 19 3/8–19 5/8 |
Hipline ease | 36.9–37.5 | 14 1/2–14 3/4 |
Upper arm ease | 10.3–11.8 | 4–4 5/8 |
Height, cm | Garment length at center back, cm | Sleeve length including shoulder width, cm |
1 (154–160) | 118.8–120.4 | 74.9–75.1 |
2 (162–168) | 123.8–125.4 | 76.5–76.7 |
3 (170–176) | 128.8–130.6 | 78.7–79 |
4 (178–184) | 133.8–135.4 | 80.4–80.6 |
Height, ft | Garment length at center back, in | Sleeve length including shoulder width, in |
1 (5’1”–5’3”) | 46 3/4–47 3/8 | 29 1/2–29 5/8 |
2 (5’4”–5’6”) | 48 3/4–49 3/8 | 30 1/8–30 1/4 |
3 (5’7”–5’9”) | 50 3/4–51 3/8 | 31–31 1/8 |
4 (5’10”–6’1”) | 52 5/8–53 1/4 | 31 5/8–31 3/4 |
Once the order is paid, within 1 minute you will receive an email with the details of the order and a link to your personal account, where the following will be available for download:
1. The pdf pattern in your chosen size, in the following formats: Letter, A4, A0 and plotter format. The size of the plotter format is indicated in the name of the document. You will need a plotter printer that can print at least 900mm width.
2. Detailed instructions which include cutting layouts, construction steps accompanied by photos, as well as instructions on how to work with Vikisews patterns (printing, taping, adjusting, sewing terminology).
If you have any questions, please let us know at info@vikisews.com
Hayden Instructions Sample
