Trinity coat
Trinity is a fully lined semi-fitted coat with an accentuated waist. The shoulder line is extended. The coat is fitted with princess seams at the front and back. The front features a separate bottom part between the center front and mid back princess seams that forms a wide pocket. The coat has a grown-on stand collar and a double-breasted sew-on snap closure. The long set-in sleeves are semi-fitted and made up of two pieces. All the seams feature decorative topstitching. Trinity is below-knee length.
Model Sofia: Height 172 cm (5’8”), Bust 84 cm (33 1/8”), Waist 64 cm (25 1/4”), Hips 90 cm (35 3/8”). Sofia is wearing size 36 in height 3.
Approximate sewing time — 3.5 days (28 hours).
To sew this coat, choose fabrics with the following properties:
- medium weight, low-stretch or non-stretch
- the fiber content can include polyurethane, polyvinyl chloride (PVC) with a woven or knit backing
- the following fabrics are recommended: faux leather
Attention! We do not recommend thin and soft faux leather.
For the lining, choose lining fabrics made of artificial fibers (viscose), blends (viscose + elastane, viscose + polyester), or synthetics (polyester, polyester + elastane).
The coat in the photo is made of faux leather. The fabric is medium weight, low-stretch, and has a knit backing. The fiber content is a blend of polyester and polyurethane. The fabric weight is 345 g/m2.
The lining is 100% viscose. The fabric weight is 100 g/m2.
The weight of the main knit interfacing is 70 g/m2. The weight of the additional one-way stretch interfacing is 50 g/m2.
1. Main fabric, 140 cm wide, with a directional print/nap, in meters:
Height, cm | Size | ||||||
34–36 | 38–40 | 42 | 44 | 46 | 48 | 50–52 | |
1 (154–160) | 2.8 | 2.85 | 3.05 | 3.1 | 3.15 | 3.25 | 3.3 |
2 (162–168) | 2.9 | 2.95 | 3.15 | 3.2 | 3.2 | 3.35 | 3.4 |
3 (170–176) | 3 | 3.05 | 3.25 | 3.25 | 3.3 | 3.45 | 3.5 |
4 (178–184) | 3.05 | 3.1 | 3.35 | 3.4 | 3.4 | 3.55 | 3.6 |
Main fabric, 55” wide, with a directional print/nap, in yards:
Height, ft | Size | ||||||
34–36 | 38–40 | 42 | 44 | 46 | 48 | 50–52 | |
1 (5’1”–5’3”) | 3 | 3 1/8 | 3 3/8 | 3 3/8 | 3 1/2 | 3 1/2 | 3 5/8 |
2 (5’4”–5’6”) | 3 1/8 | 3 1/4 | 3 1/2 | 3 1/2 | 3 1/2 | 3 5/8 | 3 3/4 |
3 (5’7”–5’9”) | 3 1/4 | 3 3/8 | 3 1/2 | 3 1/2 | 3 5/8 | 3 3/4 | 3 7/8 |
4 (5’10”–6’1”) | 3 3/8 | 3 3/8 | 3 5/8 | 3 3/4 | 3 3/4 | 3 7/8 | 3 7/8 |
2. Lining fabric, 140 cm wide, in meters:
Height, cm | Size | |||||
34–38 | 40 | 42 | 44 | 46 | 48–52 | |
1 (154–160) | 1.95 | 2 | 2 | 2.05 | 2.05 | 2.4 |
2 (162–168) | 2.05 | 2.05 | 2.05 | 2.1 | 2.1 | 2.5 |
3 (170–176) | 2.1 | 2.1 | 2.15 | 2.15 | 2.2 | 2.6 |
2.15 | 2.2 | 2.2 | 2.2 | 2.25 | 2.65 | |
Lining fabric, 55” wide, in yards:
Height, ft | Size | ||||
34–40 | 42 | 44 | 46 | 48–52 | |
1 (5’1”–5’3”) | 2 1/8 | 2 1/8 | 2 1/4 | 2 1/4 | 2 5/8 |
2 (5’4”–5’6”) | 2 1/4 | 2 1/4 | 2 1/4 | 2 1/4 | 2 3/4 |
3 (5’7”–5’9”) | 2 1/4 | 2 3/8 | 2 3/8 | 2 3/8 | 2 7/8 |
4 (5’10”–6’1”) | 2 3/8 | 2 3/8 | 2 3/8 | 2 1/2 | 2 7/8 |
IMPORTANT! When purchasing fabric, please account for shrinkage and buy 5% more than required.
3. Heavyweight interfacing, knit or woven, 140 cm wide, in meters:
Height, cm | Size | ||||||
34–36 | 38–40 | 42 | 44 | 46 | 48 | 50–52 | |
1 (154–160) | 3.3 (2.8 + 0.5) | 3.35 (2.85 + 0.5) | 3.55 (3.05 + 0.5) | 3.65 (3.1 + 0.55) | 3.7 (3.15 + 0.55) | 3.8 (3.25 + 0.55) | 3.85 (3.3 + 0.55) |
2 (162–168) | 3.4 (2.9 + 0.5) | 3.45 (2.95 + 0.5) | 3.65 (3.15 + 0.5) | 3.75 (3.2 + 0.55) | 3.75 (3.2 + 0.55) | 3.9 (3.35 + 0.55) | 3.95 (3.4 + 0.55) |
3 (170–176) | 3.5 (3 + 0.5) | 3.55 (3.05 + 0.5) | 3.75 (3.25 + 0.5) | 3.75 (3.25 + 0.55) | 3.85 (3.3 + 0.55) | 4 (3.45 + 0.55) | 4.05 (3.5 + 0.55) |
4 (178–184) | 3.55 (3.05 + 0.5) | 3.6 (3.1 + 0.5) | 3.85 (3.35 + 0.5) | 3.95 (3.4 + 0.55) | 3.95 (3.4 + 0.55) | 4.1 (3.55 + 0.55) | 4.15 (3.6 + 0.55) |
Heavyweight interfacing, knit or woven, 55” wide, in yards:
Height, ft | Size | ||||||
34–36 | 38–40 | 42 | 44 | 46 | 48 | 50–52 | |
1 (5’1”–5’3”) | 3 5/8 (3 + 1/2) | 3 5/8 (3 1/8 + 1/2) | 3 7/8 (3 3/8 + 1/2) | 4 (3 3/8 + 5/8) | 4 (3 1/2 + 5/8) | 4 1/8 (3 1/2 + 5/8) | 4 1/4 (3 5/8 + 5/8) |
2 (5’4”–5’6”) | 3 3/4 (3 1/8 + 1/2) | 3 3/4 (3 1/4 + 1/2) | 4 (3 1/2 + 1/2) | 4 1/8 (3 1/2 + 5/8) | 4 1/8 (3 1/2 + 5/8) | 4 1/4 (3 5/8 + 5/8) | 4 3/8 (3 3/4 + 5/8) |
3 (5’7”–5’9”) | 3 7/8 (3 1/4 + 1/2) | 3 7/8 (3 3/8 + 1/2) | 4 1/8 (3 1/2 + 1/2) | 4 1/8 (3 1/2 + 5/8) | 4 1/4 (3 5/8 + 5/8) | 4 3/8 (3 3/4 + 5/8) | 4 3/8 (3 7/8 + 5/8) |
4 (5’10”–6’1”) | 3 7/8 (3 3/8 + 1/2) | 3 7/8 (3 3/8 + 1/2) | 4 1/4 (3 5/8 + 1/2) | 4 3/8 (3 3/4 + 5/8) | 4 3/8 (3 3/4 + 5/8) | 4 1/2 (3 7/8 + 5/8) | 4 1/2 (3 7/8 + 5/8) |
4. Heavyweight one-way stretch fusible interfacing, 140 cm (55”) wide, for all sizes in all heights — 0.45 m (1/2 yd)
5. Stitched bias-cut fusible stay tape, for all sizes in all heights — 2.9 m (3 1/8 yd)
6. Paper-backed fusible web tape, 1 cm (3/8”) wide, for all sizes:
Height, cm | Length, m |
1 (154–160) | 12 |
2 (162–168) | 13 |
3 (170–176) | 13 |
4 (178–184) | 13 |
Height, ft | Length, yd |
1 (5’1”–5’3”) | 13 1/8 |
2 (5’4”–5’6”) | 14 1/4 |
3 (5’7”–5’9”) | 14 1/4 |
4 (5’10”–6’1”) | 14 1/4 |
7. Paper-backed fusible web tape, 2 cm (3/4”) wide, for all sizes in all heights — 1.7 m (1 7/8 yd)
8. Four metal snaps, 2.1 cm (7/8”) in diameter
9. One pair of sleeve heads
10. One pair of shoulder pads, 2 cm (3/4”) high
11. Matching thread — 1 spool for the sewing machine
12. Matching topstitching thread (for example, Madeira No. 35) — 2 spools
- sewing machine for construction
- stitch-in-the-ditch foot for the sewing machine (optional)
- walking or teflon foot for the sewing machine
Ease type | Ease measurement, cm | Ease measurement, in |
Bust ease | 4.3–5.3 | 1 3/4–2 1/8 |
Waistline ease | 9.4–9.5 | 3 3/4 |
Hipline ease | 10.8–14.5 | 4 1/4–5 3/4 |
Upper arm ease | 9.9–11.5 | 3 7/8–4 1/2 |
Height, cm | Back length, cm | Sleeve length (estimated), cm |
1 (154–160) | 117.9–119.7 | 58.9–60.6 |
2 (162–168) | 121.9–123.7 | 60.9–62.6 |
3 (170–176) | 125.9–127.7 | 63–64.6 |
4 (178–184) | 129.9–131.7 | 65–66.6 |
Height, ft | Back length, in | Sleeve length (estimated), in |
1 (5’1”–5’3”) | 46 3/8–47 1/8 | 23 1/4–23 7/8 |
2 (5’4”–5’6”) | 48–48 3/4 | 24–24 5/8 |
3 (5’7”–5’9”) | 49 5/8–50 1/4 | 24 3/4–25 3/8 |
4 (5’10”–6’1”) | 51 1/8–51 7/8 | 25 5/8–26 1/4 |
Once the order is paid, within 1 minute you will receive an email with the details of the order and a link to your personal account, where the following will be available for download:
1. The pdf pattern in your chosen size, in the following formats: Letter, A4, A0 and plotter format. The size of the plotter format is indicated in the name of the document. You will need a plotter printer that can print at least 900 mm width.
2. Detailed instructions which include cutting layouts, construction steps accompanied by photos, as well as instructions on how to work with Vikisews patterns (printing, taping, adjusting, sewing terminology).
If you have any questions, please let us know at info@vikisews.com
Trinity instructions Sample
